70-litre blast pot

The CYM CY-70 blast pot is the most compact model in the CY line: 70-litre capacity, 300 kg of shot loading and a portable wheeled frame. Weighing 70 kg empty and measuring Ø400 × 800 mm (Ø15¾" × 31½"), the CY-70 is the ideal solution for high-frequency operations where mobility and fast start-up are critical.
The CY-70 is available in four control system variants — manual (M), with depressurization (D), dual (DD) and Pinch (P) — and accepts No.3 (Ø5 mm) and No.4 (Ø6 mm) Venturi nozzles for metallic or mineral abrasives at up to 7 kg/cm² (100 PSI). The modular design allows the basic manual control unit to be upgraded to any remote Dead-Man control system using easily installed conversion kits.
El modelo CY-70 se entrega en cuatro variantes de sistema de control —manual (M), con despresurización (D), dual (DD) y Pinch (P)— y admite boquillas Venturi Nro.3 (Ø5 mm) y Nro.4 (Ø6 mm) para proyección de abrasivos metálicos o minerales hasta 7 kg/cm². El diseño modular permite transformar el equipo básico de control manual en cualquier sistema de control a distancia mediante kits de conversión de fácil montaje.

• Capacity: 70 litres — 300 kg shot loading
• Compact portable wheeled frame (transport in empty condition)
• 1 nozzle outlet — No.3 (Ø5 mm) and No.4 (Ø6 mm) Venturi nozzles
• Maximum working pressure: 7 kg/cm² (100 PSI)
• Autonomy of up to 40 minutes per charge (No.3 nozzle)
• Four control systems available: M · D · DD · P
• Modular design — upgradeable via conversion kits without replacing the base unit
• ASME construction — automatic pop-up fill valve and pressure safety valve
